Description
AE-4S 55A is a compact 4S 32-bit ESC delivering 55 A continuous current in a 45.5 × 52.2 mm footprint. Supports BLHeli-S and novaX ef 1.0 firmware. Designed for Blade8-class platforms requiring lightweight power delivery.
Basic Specifications
Size
45.5 × 52.2 mm
Mounting Hole
30 × 30 mm / Φ 4 mm
Weight
14.8 g
Voltage Range
3 – 4S LiPo (12.6 – 16.8 V)
Constant Current
55 A
Burst Current
65 A
Capacitor
470 µF / 35 V
PWM Frequency
24 – 48 kHz (Bluejay 96 kHz)
Supported Protocols
DShot150 / 300 / 600, MultiShot, OneShot
Firmware
BLHeli-S, novaX ef 1.0
Pinout coming soon
Firmware downloads coming soon
