Description
Large outrunner brushless motor at KV100 for 12–14S LiPo industrial UAVs. Φ90 × 78.9 mm stator delivers heavy thrust for survey and cargo platforms.
Basic Specifications
Stator Dimensions
Φ90 × 78.9 mm
Slots / Poles
36N40P (20 pole pairs)
Motor Weight
1150 g
KV Value
KV100
Rated Voltage
44.4 ~ 50.4 V
Max Current
54 A
Max Power
2700 W
Recommended Prop
28 ~ 30 inch (30×11)
Operating Temp
-20 ~ +85 ℃
Load Performance Data
14S LiPo, 20%–100% throttle on static thrust stand. Measured values; rated specs may differ.
Propeller 30 × 11 · Thrust (g) vs Throttle (%)
Propeller 30 × 11
| Throttle | Voltage (V) | Thrust (g) | Torque (N·m) | Current (A) | Power (W) | Eff (g/W) | Temp (℃) |
|---|---|---|---|---|---|---|---|
| 20% | 50.39 | 772 | 0.323 | 1.07 | 54 | 14.3 | 30 |
| 40% | 50.31 | 3059 | 1.091 | 5.38 | 270 | 11.3 | — |
| 60% | 50.14 | 6351 | 2.300 | 15.69 | 786 | 8.0 | — |
| 80% | 49.84 | 10358 | 3.797 | 32.20 | 1605 | 6.5 | — |
| 100% | 47.85 | 14708 | 5.280 | 54.27 | 2596 | 5.9 | — |
