Description
Outrunner brushless motor at KV620 for 6S LiPo platforms.
Basic Specifications
Slots / Poles
12N14P (7 pole pairs)
KV Value
KV620
Rated Voltage
22.2 V (6S LiPo)
Max Current
72.5 A
Recommended Prop
15 × 8
Operating Temp
-20 ~ +85 ℃
Load Performance Data
6S LiPo, 20%–100% throttle on static thrust stand. Measured values; rated specs may differ.
Propeller 15 × 8 · Thrust (g) vs Throttle (%)
Propeller 15 × 8
| Throttle | Voltage (V) | Thrust (g) | Torque (N·m) | Current (A) | Power (W) | Eff (g/W) | Temp (℃) |
|---|---|---|---|---|---|---|---|
| 20% | 25.10 | 392 | 0.086 | 1.57 | 39 | 9.7 | 40.1 |
| 40% | 25.08 | 1596 | 0.286 | 8.25 | 207 | 7.8 | — |
| 60% | 24.82 | 2935 | 0.540 | 23.03 | 571 | 5.2 | — |
| 80% | 24.38 | 4483 | 0.891 | 47.05 | 1147 | 3.9 | — |
| 100% | 23.08 | 5618 | 1.091 | 72.54 | 1674 | 3.4 | — |
