Description
Outrunner brushless motor at KV600 for 6S LiPo platforms, biased toward efficient cruise applications.
Basic Specifications
Slots / Poles
12N14P (7 pole pairs)
KV Value
KV600
Rated Voltage
22.2 V (6S LiPo)
Max Current
48.6 A
Max Power
1180 W
Recommended Prop
13 × 7
Operating Temp
-20 ~ +85 ℃
Load Performance Data
6S LiPo, 20%–100% throttle on static thrust stand. Measured values; rated specs may differ.
Propeller 13 × 7 · Thrust (g) vs Throttle (%)
Propeller 13 × 7
| Throttle | Voltage (V) | Thrust (g) | Torque (N·m) | Current (A) | Power (W) | Eff (g/W) | Temp (℃) |
|---|---|---|---|---|---|---|---|
| 20% | 25.18 | 311 | 0.051 | 1.26 | 32 | 8.8 | 35.4 |
| 40% | 25.10 | 1021 | 0.151 | 5.68 | 142 | 7.9 | — |
| 60% | 24.89 | 2136 | 0.313 | 16.58 | 413 | 5.5 | — |
| 80% | 24.50 | 3471 | 0.542 | 35.79 | 877 | 4.5 | — |
| 100% | 23.95 | 4681 | 0.782 | 62.48 | 1496 | 3.5 | — |
