Description
Micro brushless motor rated for 2S LiPo (7.4 V). Ultra-compact form factor for tiny whoop and micro drone platforms.
Basic Specifications
Slots / Poles
12N14P (7 pole pairs)
Rated Voltage
7.4 V (2S LiPo)
Max Current
7.08 A
Max Power
58.8 W
Load Performance Data
2S LiPo, sea-level static thrust stand. Measured values; rated specs may differ.
Propeller 2016S · Thrust (g) vs Throttle (%)
Propeller 2016S
| Throttle | Voltage (V) | Thrust (g) | Torque (N·m) | Current (A) | Power (W) | Eff (g/W) | Temp (℃) |
|---|---|---|---|---|---|---|---|
| 20% | 8.45 | 7.3 | 0.0001 | 0.14 | 1.1 | 6.4 | 31.5 |
| 40% | 8.44 | 30.2 | 0.0015 | 0.91 | 7.7 | 3.9 | 31.4 |
| 60% | 8.41 | 60.0 | 0.0033 | 2.33 | 19.6 | 3.1 | 31.4 |
| 80% | 8.37 | 88.5 | 0.0050 | 4.25 | 35.6 | 2.5 | 32.0 |
| 100% | 8.31 | 121.7 | 0.0071 | 7.08 | 58.8 | 2.1 | 32.3 |
