Description
AP-M10 is a compact GNSS module based on the u-blox M10 series, with an integrated BMM350 compass and built-in ceramic patch antenna. Multi-constellation tracking (BDS / GPS / GLONASS / Galileo / QZSS) provides H 1.5 m / V 2.5 m RMS accuracy and a cold start under 27 seconds. UART (TTL) interface and 1–18 Hz update rate suit close-coupled FC integration in an 18.2 × 18.2 mm, 8 g footprint.
Basic Specifications
Chipset
u-blox M10 Series
Compass
BMM350
Satellite Systems
BDS / GPS / GLONASS / Galileo / QZSS
Antenna Band
L1 Band Only
Antenna Type
Built-in Ceramic Patch
Single-Point Accuracy
H 1.5 m / V 2.5 m (RMS)
Cold Start
< 27 sec
Hot Start
< 1 sec
Update Rate
1 – 18 Hz (Default 10 Hz)
Data Format
NMEA / UBX
Comm. Protocol
UART (TTL)
I/O Ports
1× UART
Size
18.2 × 18.2 × 8 mm
Weight
8 g
Operating Temp
-40 ~ +85 ℃
Operating Voltage
3.3 – 5.0 V
