AE-6S 60A

AM32 bootloader V16, built for the 32K memory layout with PB4 as the signal pin — matching the boards as shipped. The "32K" is the layout the bootloader assumes, not its own size: the bootloader occupies 0x0000–0x0FFF (about 3.7 KB) and the application starts at 0x1000. This layout places the settings EEPROM at 0x7C00 and needs no 4-way address shift, so the configurator talks to it directly. Byte-identical to the verified 2.27 bootloader and never rebuilt. Flash on a blank or bricked board via SWD/ST-Link, then load the application over 4-way passthrough.

AM32 application v2.29 (novaX_12S_F415) with the do-mi-sol startup chime, played on arming. The motor coasts when throttle is cut, and that is now a stored setting rather than a hard-coded one — ticking Complementary PWM in the configurator's Motor section enables deceleration braking and makes Running brake level and Brake strength effective, while leaving it clear lets the motor freewheel. Low-throttle startup follows the Startup power setting: at 24 kHz the startup duty is 9.0% and the slider spans 6.5–11.5%. Keep Running brake level at 10 — lowering it adds dead-time compensation to the startup duty and doubles it. Occupies flash pages 4–23 plus 30 only, so it never touches the bootloader or the settings EEPROM, and it reads the bootloader devinfo at boot so the same image works under a 32K / 64K / 128K bootloader. Flash over an existing bootloader via the AM32 configurator / 4-way passthrough.

V16 bootloader (32K layout) + application v2.29 + a factory settings EEPROM at 0x7C00, in one image for a single SWD/ST-Link flash on a blank or bricked board. The EEPROM carries Motor KV 1140 to match the actual motors, coasting enabled, Startup power 100, 24–48 kHz variable PWM and protocol AUTO — so flashing this also resets every setting to those defaults. Include the EEPROM block: a Mass Erase leaves that area at 0xFF and the firmware then reads input_type as 255, which selects no input protocol at all (main.c gates it on input_type < 10). SWD only: do not flash a BootApp image over 4-way passthrough, whose 16-bit addressing truncates the EEPROM address and writes it to the wrong place.
