Description
AC-THE02F is a thermal imaging module based on a Vox detector, available in SoC and FPGA variants to match different integration and processing requirements.
Basic Specifications
Detector Type
Vox
Resolution
640 × 512
Pixel Pitch
12 µm
NETD
≤ 40 mK (@F/1.0, 300K)
Weight (core w/o lens)
< 34 g
Frame Rate (SoC)
Typ. 30 Hz
Frame Rate (FPGA)
PAL 25/50 Hz · NTSC 30/60 Hz
Output (SoC)
USB 2.0
Output (FPGA)
CVBS
Core Dimension (SoC)
21 × 21 × 25 mm
Core Dimension (FPGA)
20 × 20 × 38 mm
Lens Options (SoC)
9 mm (HFOV 48.8°) / 19 mm (HFOV 23.2°) / 13.4 mm (HFOV 32°)
Lens Options (FPGA)
9 mm (20 × 20 × 38 mm) / 6.8 mm (HFOV 62°)
